Reliable Filtration, Made Simple
The AquaSolis ASMF2850 uses sand or glass filter media to trap dirt and debris as pool water passes through the filter bed, helping keep the water clear and clean. Its generous media area supports effective filtration and consistent water flow for everyday pool use.
The UV-stabilised filament-wound fibreglass tank is built for strength and long service life outdoors, while the 50mm 6-way multiport valve makes filtering, backwashing and rinsing easy to manage. An integrated sight glass and liquid-filled pressure gauge help you monitor filter operation and check when backwashing is complete.
Key Features
- Sand or Glass Media: Compatible with either filter media option to suit your preferred pool setup.
- Filament-Wound Fibreglass Tank: UV-stabilised construction for strength, outdoor durability and long service life.
- Generous Media Area: Gives pool water plenty of contact with the filtration bed for consistent, effective filtering.
- 50mm Bolt-Down Multiport Valve: 6-way operation makes it simple to switch between filter, backwash, rinse, waste, recirculate and closed functions.
- Integrated Sight Glass: Makes it easy to check water clarity during backwashing and rinsing.
- Liquid-Filled Pressure Gauge: Provides a clear view of filter operating pressure at a glance.
- Robust ABS Barrel Unions: Help make installation and routine servicing straightforward.
- High Operating Pressure: Cylindrical tank construction supports operation up to 370 kPa.
Technical Specifications
| Model | ASMF2140 | ASMF2540 | ASMF2550 | ASMF2850 | ASMF3250 |
|---|---|---|---|---|---|
| Filter Size (inches) | 21 | 25 | 25 | 28 | 32 |
| Maximum Flow Rate (L/min / m³/h) | 192 / 12 | 270 / 16 | 305 / 18 | 320 / 20 | 420 / 25 |
| Approx. Filtration Area (m²) | 0.21 | 0.30 | 0.30 | 0.38 | 0.50 |
| Maximum Operating Pressure (kPa) | 370 | ||||
| Tank Diameter (mm) | 534 | 635 | 635 | 700 | 820 |
| Overall Height incl. MPV (mm) | 867 | 967 | 1027 | 1080 | 1180 |
| Multiport Valve Size (mm) | 40 | 40 | 50 | 50 | 50 |
| MPV Connection Type | Clamp Down | Clamp Down | Bolt Down | Bolt Down | Bolt Down |
| Sand Required (kg) | 85 | 155 | 155 | 210 | 250 |
| Fine Glass Media Required (kg) | 45 | 75 | 75 | 105 | 150 |
| Coarse Glass Media Required (kg) | 30 | 45 | 45 | 60 | 75 |
| Warranty |
Tank: 10 years Multiport Valve: 3 years Infield: 1 year |
||||
Please note: Filter media is not included.
| SKU | SP-ASMF2850 |
|---|---|
| Package Length | 74 cm |
| Package Width | 74 cm |
| Package Height | 116 cm |
| Brand | AquaSolis |
| Model | ASMF2850 - 28" Media Filter with 50mm 6-Way MPV |
| Product Type | Sand Filter |
| Shipping Type | Bulky - Large |
| Warranty | 10 Years Tank, 3 Years Valve, 1 Year Components |
| Diameter (inches) | 28 |
| Max Flow rate (LPM) | 320 |
| Sand required (kg) | 210 Kg |
| Zeolite/Glass Required (kg) | Glass: 105kg (fine), 60kg (coarse) |
| Plumbing | 50mm |
| Multi Port Valve | 50mm |
| Dimensions LxWxH (mm) | 700 × 700 × 1080 |
